STEP 3
#2 =
Attach the rear U bar to the side channel. Loosely bolt
clamp plates together with bolts E, washer I and lock nut J.
#1 = Position rear cross bar
and adjust the cross bar
bolt
until mounting bracket aligns with van roof top bracket.
#1 = There are
4 mounting feet in your box. There are
4 identical feet
.
#3 = Place the spacer
N inside the mounting
brackets. Loosely bolt the feet to slider brackets
using bolts
K, washers L and lock nuts M.
#2 = Position the feet
bracket into the
slider brackets on the cross bars.
N
L
M
L
K
STEP 4
E
I
J
