Page 2

Tools Needed

Hardware Pack Cont'

8' Tape Measure

1/2" End Wrench

(j)

1/2" Socket

9/16" End Wrench

Qty 24 -

9/16" Socket

Hammer

5/16" Nylock Nut

7/16 Socket

(k)
Qty 4 -

Hardware Pack

3/8" x 4" L Hex Bolt

(a)

(l)

Qty 4 -

Qty 8 -

1/2" x 2-1/4" Botton Head Bolt

3/8" SAE Flat Washer

(b)

(m)

Qty 4 -

1/2" Nylock Jam Nut

3/8" Nylock Nut

(d)

(n)

Qty 4 -

M8 x 20 Hex Bolt

Mounting Bracket Spacer

(e)

(p)

Qty 16 -

Qty 4 -

5/16"-18 x 1" L Carriage Bolt

1/2" SAE Flat Washer

(g)

(q)

Qty 8 -

Qty 4 -

5/16"x 1-1/4" L Bottom Head Bolt

M8 Nylock Nut

(i)

(r)

Qty 32-

Qty 4 -

5/16" Flat Washer

Fender Washer 24mmOD x 2mmTK

Mounting Kit

(s)

(y)

Qty 8 -

Qty 4 -

M8 x 20 Hex Bolt

5/16"-18 x 1-3/4" Hex Bolt

(t)

(z)

Qty 36 -

Qty 8 -

5/16" Flat Washer

M8 J Nut

(u)

(c)

Qty 12 -

5/16"-18 Nyloc Nut

5/16"-18 x1" Hex Bolt

(v)

(f)

Qty 12 -

Qty 8 -

5/16" Lock washer

M8 x 30 Hex Bolt

(x)

(h)

Qty 4 -

OD 1-3/4" Rubber Washer

Mount Clip-Promaster

(w)

(o)

Qty 2 - Left

Qty 2 - Right

Rail MNT Base-Promaster-NV

For TECHNICAL SUPPORT Call: 800-343-7486 Monday - Friday 7:00 A.M. to 4:00 P.M (PST)

80080 Harware List
