Kargo Master Full Size Van Top Mount Ladder Rack - Manual (Page 7)

A
B
A
B
GOOP APPLICATION
Apply a healthy air tight bead of goop
around every swaged joint as shown, to
prevent moisture from leaking into and out
of the joint. If this is not done properly, the
inside surface of the tubes can rust and
rusty water can leak out. Maintain this
joint seal throughout the life of your rack.
Swaged joint & holes
Smooth goop at swaged joint & holes
'//0
'//0
STEP 1
#1 = Cover entire swedge joints with
goop and slide FRONT U- BAR onto side
rails and bolt together with bolts
A, and
jam nut B.
G
O
OP
GOOP
STEP 2
#1 = Cover entire swedge joints with
goop and slide REAR U- BAR onto side
rails and bolt together with bolts
A, and
jam nut
B.
TMCS_3:1
