Kargo Master Pro III Steel Ladder Rack – With A Camper Shell (80030) - Manual (Page 3)

E (2 ea.)
5/16" x 2 1/4"
Button Head Bolt
F (8 ea.)
5/16" x 3/4"
Button Head Bolt
O
(4 ea.)
1/2" Lock Washer
H
A G
J
K
( 6 ea.)
1/2" SAE Flat Washer
(22 ea.)
3/8" SAE Flat Washer
(14 ea.)
5/16" Flat Washer
(4 ea.)
L (2 ea.)
M (11 ea.) N (14 ea.)
(4 ea.)
Shown Actual Size Shown Actual Size
1/2" x 1 1/2"
Hex Bolt
5/16" x 3/4"
Carriage Bolt
1/2" Jam Nut 3/8" Lock Nut 5/16" Lock Nut
D (8 ea.)
3/8" x 1 3/4"
Button Head
R
(2 ea.)
1/2" Rubber Washer
© 2006 KARGO MASTER --Pro 3-KS _1.1
C (3 ea.)
3/8" x 2 1/4"
Button Head
B (2 ea.)
1/2" x 2 1/4"
Button Head Bolt
P (4 ea.)
5/16" x 3/8"
Allen Head Set Screw
