Kargo Master Pro III Steel Ladder Rack – Without A Camper Shell (80020) - Manual (Page 3)

2011 KargoMaster-'Pro 3 & 4' _4.1
E (2 ea.)
5/16" x 2 1/4"
Button Head Bolt
F (8 ea.)
5/16" x 3/4"
Button Head Bolt
H
A
G
J
K
(14 ea.)
1/2" SAE Flat Washer
(22 ea.)
3/8" SAE Flat Washer
U
(4 ea.)
3/8" Lock Washer
(14 ea.)
5/16" Flat Washer
(4 ea.)
L (6 ea.)
M (10 ea.) N (14 ea.)
(4 ea.)
1/2" x 3 1/2"
Hex Bolt
5/16" x 3/4"
Carriage Bolt
1/2" Jam Nut
3/8" Lock Nut 5/16" Lock Nut
D (8 ea.)
3/8" x 1 3/4"
Button Head
C (2 ea.)
3/8" x 2 1/4"
Button Head
T (2 ea.)
3/8" x 16 x 2 1/2"
Button Head Bolt
B (2 ea.)
1/2" x 2 1/4"
Button Head Bolt
S (6 ea.)
1/2" x 13 x 2 1/2"
Button Head Bolt
P (4 ea.)
5/16" x 3/8"
Allen Head Set Screw
Q (2 ea.)
3/8” T Nut
R (6 ea.)
Bed Rail
Clamps
(yellow zinc plated, grade 5)
(yellow zinc plated, grade 5)
(yellow zinc plated, grade 5)
