Kargo Master Pro II Steel Ladder Rack – Without A Camper Shell (0104) - Manual (Page 3)

H
S
F Q
O
U
L
E
(12 ea.)
1/2" SAE Flat Washer
(5 ea.)
1/2" Lock Washer
(28 ea.)
3/8" SAE Flat Washer
(9 ea.)
5/16" Flat Washer
(2 ea.)
3/8" Lock Washer
(4 ea.)
I (7 ea.) R (12 ea.) M (9 ea.)
(4 ea.) (4 ea.)
1/2" x 3-3/4"
Hex Bolt
P (4 ea.)
1/2" x 1"
Hex Bolt
3/8" x 3"
Hex Bolt 5/16" x 3/4"
Carriage Bolt
1/2" Jam Nut 3/8" Lock Nut 5/16" Lock Nut
D (8 ea.)
3/8" x 1 3/4"
Button Head
© 2012 KARGO MASTER - Pro 2 12_1.1
A (
2 ea.)
3/8" x 16 x 2 1/2"
Button Head
N (2 ea.)
3/8" Coupling Nut
W (2 ea.)
Plastic Knob
K (2 ea.)
3/8" x 3 1/2"
Tap Bolt
B (
2 ea.)
3/8” T Nut
(2 ea.)
Rear Pin
& Cap
C (
6 ea.)
Bed Rail
Clamps
G (
2 ea.)
1/2" x 2 3/4"
Button Head Bolt
V (
6 ea.)
1/2" x 2 1/2"
Button Head Bolt
J
