Order details
Dial thermometer, Class 1.5, Type 608202
Order code
(9)
Material of probe / support tube
1
26
stainless steel (CrNi, 1.4571)
96
copper (Cu) / brass (CuZn) (up to 200°C)
95
stainless steel (CrNi, 1.4571) — probe / brass (CuZn) — support tube
(above 250°C)
(10)
Material of process connection (PA)
1
00
none (TF01 and TF11 only)
01
steel (St)
26
stainless steel (CrNi, 1.4571)
46
brass (CuZn)
(11)
Fitting length of process connection (PA)
1
(dimension EL or S)
0
minimum fitting length TF 11 (active probe dimension)
50
0
50 mm
100
100 mm
150
150 mm
200
200 mm
. . .
special length (specify in plain text, in 50 mm steps)
(12)
Extra codes (TZ)
000
no extra code
455
mounting bracket at rear
with 60 mm housing dia. and 72 x 72 mm bezel
315
capillary reinforcement on housing and probe
(not with FL 21)
522
customized scale
Special versions on request!
1
See Data Sheet 608730 for description and features
2
Screw-in spigot to DIN 3852 Form A.
3
List extra codes in sequence, separated by commas.
Order code
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
608202
/
. . . .
-
. . .
-
. .
-
. . . .
-
. . .
-
. .
-
. . .
-
. .
-
. .
-
. . .
/
. .
,
. . .
Order example
608202
/
2660
-
832
-
11
-
2000
-
161
-
6
-
104
-
96
-
46
-
150
/
000
3
