Data sheet 90.2721
Page 6/6
1. State extra codes one after the other, separated by commas.
Note:
*
Please select the precise version from the respective data sheets 90.1210 and 90.2210
and specify the fitting length and the sheath diameter in the order details.
**
For extra code standard calibration, the temperatures 0, 100 and 200 °C are used as inspection points.
Different and further inspection points are optionally selectable under extra code 775.
Order details:
Temperature measuring chain
(1) Display unit basic type
902722/20
Precision display unit P700
1-channel/resolution 0.1 °C/-200 to +850 °C
Pt100, thermocouples: type K, J, L, N, R, S, T
902722/25
Precision display unit P705
2-channel/resolution 0.1 °C/-200 to +850 °C
Pt100, thermocouples: type K, J, L, N, R, S, T
902722/30
Precision display unit P750
1-channel/resolution 0.01 °C/0.1 °C/-200 to +850 °C
Pt100, thermocouples: type K, J, L, N, R, S, T
902722/35
Precision display unit P755
2-channel/resolution 0.01 °C/0.1 °C/-200 to +850 °C
Pt100, thermocouples: type K, J, L, N, R, S, T
(2) Operating temperature, temperature probe, in °C
x x x x
135
-200 to +450 °C (Precision RTD temperature probe including adapter cable)
x x x x
150
-200 to +600 °C (RTD temperature probe), basic type 902240/20...*
x x x x
185
-200 to +1200 °C (Thermocouples), basic type 901240/20-1043... including adapter cable*
x x x x
385
-50 to +250 °C (Precision RTD temperature probe including adapter cable)
x x x x
415
-50 to +600 °C (RTD temperature probe), basic type 902240/20...*
(3) Temperature probe sheath diameter D in mm
x x x x
3
Ø 3 mm
x x x x
4.5
Ø 4.5 mm
x x x x
...
Specification in plain text (only for (2) selection 150, 185 and 415)*
(4) Temperature probe fitting length in mm
x x x x
200
200 mm (not for (2) selection 135)
x x x x
300
300 mm
x x x x
400
400 mm (not for (2) selection 385)
x x x x
...
Specification in plain text (50 mm steps, only for (2) selection 150, 185 and 415)*
(5) Number of temperature probes
x x x x
...
Specifications in plain text
(6) Extra codes
x x x x
000
no extra code
x x x x
773
DAkkS (DKD) calibration (standard, display values only)**
x x x x
774
DAkkS (DKD) calibration (standard, with RTD temperature value table)**
x x x x
775
DAkkS (DKD) calibration (service, specify inspection points in plain text)
x x x x
781
Connector power pack AC 230 V for P700 series
x x x x
782
Service box (plastic) with foam padding
x x x x
923
"DE-Graph“ evaluation software
x
926
With storage module for 6.000 measured values
(1)
(2)
(3)
(4)
(5)
(6)
Order code
-
-
-
-
/
, ...
Order example
902722/35 -
135
-
3
-
200
-
2
/ 775, -40, 0, 100°C
1
