Page 5
2011-03-31/00331822
Data sheet 90.2721
Page 5/6
JUMO GmbH & Co. KG
Delivery address:Mackenrodtstraße 14,
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone:
+49 661 6003-0
Fax:
+49 661 6003-607
e-mail:
Internet:
www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
e-mail:
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
8 Technology Boulevard
Canastota, NY 13032, USA
Phone:
315-697-JUMO
1-800-554-JUMO
Fax:
315-697-5867
e-mail:
Internet: www.jumo.us
1. State extra codes one after the other, separated by commas.
Note:
**
For extra code standard calibration, the temperatures 0, 100 and 200 °C are used as inspection points.
Different and further inspection points are optionally selectable under extra code 775.
Temperature probe connection
An 1.5 m long silicone insulated connection line is contained in the scope of delivery.
Order details:
Precision RTD temperature probe
(1) Basic type
902721/10
Precision RTD temperature probe
as per DIN EN 60751
Pt100 4-wire/Lemosa connector/
connection cable/-50 to +250 °C
902721/15
Precision RTD temperature probe
as per DIN EN 60751
Pt100 4-wire/Lemosa connector/
connection cable/-200 to +450 °C
(2) Sheath diameter D in mm
x x
3
Ø 3 mm
x x
4.5
Ø 4.5 mm
(3) Fitting length EL in mm
x
200
200 mm
x x
300
300 mm
x
400
400 mm
(4) Packaging
x x
10
In twist pack
(5) Extra codes
x x
000
no extra code
x x
774
DAkkS (DKD) calibration (standard, with RTD temperature value table)**
x x
775
DAkkS (DKD) calibration (service, specify inspection points in plain text)
(1)
(2)
(3)
(4)
(5)
Order code
-
-
-
/
,...
Order example
902721/10 -
3
-
200
-
10
/ 775, -10, 0, +25°C
1
