Order specifications:
Push-in RTD temperature probe with connection head form B
(1) Basic type
902120/10
Push-in RTD temperature probes
with continuous sheath
(2) Operating temperature in °C
x 150 -200 to +600 °C
x 402 -50 to +400 °C (standard)
x 415 -50 to +600 °C
(3) Measuring insert
x 1001 1x Pt100 in 3-wire-circuit
x 1003 1x Pt100 in 2-wire circuit
x 1011 1x Pt100 in 4-wire circuit
x 2001 2x Pt100 in 3-wire circuit
x 2003 2x Pt100 in 2-wire circuit
(4) Tolerance class as per DIN EN 60751
x 1 Class B (standard)
x 2 Class A
(5) Sheath diameter D in mm
x 9 Ø 9 mm
x 11 Ø 11 mm
x 15 Ø 15 mm
(6) Nominal length NL in mm (100
≤ΝΛ
£
1000)
x 180 180 mm, fitting length (EL) 100 to 140 mm
x 270 270 mm, fitting length (EL) 100 to 230 mm
x 290 290 mm, fitting length (EL) 100 to 250 mm
x 350 350 mm, fitting length (EL) 100 to 310 mm
x 410 410 mm, fitting length (EL) 100 to 370 mm
x 420 420 mm, fitting length (EL) 100 to 400 mm
x 500 500 mm, fitting length (EL) 100 to 460 mm
x 710 710 mm, fitting length (EL) 100 to 670 mm
x 1000 1000 mm, fitting length (EL) 100 to 960 mm
x ... Specification in plain text (50 mm steps)
(7) Process connection
x 000 without process connection
x 254 Sheath screw connection G 1/2 (for a 15 mm diameter
only)
x 663 Sheet steel flange Ø 9 mm
x 665 Sheet steel flange Ø 11 mm
x 668 Stop flange Ø 15 mm, DIN 43734
(8) Extra codes
x 000 no extra code
x 320 terminal head Form BUZ
x 321 terminal head Form BUZH
x 322 Connection head form BBK
x 330 1x analog transmitter, 4 to 20 mA 2 output, data sheet 70.7030
x 331 1x transmitter programmable output 4 to 20 mA/20 to 4 mA
3
, data sheet 70.7010
x 333 1x analog transmitter, 0 to 10 V 2 output, data sheet 70.7030
x 334 2x analog transmitters, 4 to 20 mA 2 output, data sheet 70.7030
x 335 2x transmitter programmable output 4 to 20 mA/20 to 4 mA 3 , data sheet 70.7010
x 337 2x analog transmitters, 0 to 10V 2 output, data sheet 70.7030
x 859 1x Wtrans B programmable head transducer with radio transmission, data sheet 70.7060
(1) (2) (3) (4) (5) (6) (7) (8)
Order code - - - - - - / , ... 1
Order example 902120/10 - 402 - 1001 - 1 - 9 - 410 - 663 / 000
1 List extra codes in sequence, separated by commas.
2 Specify measuring range in plain text.
3 Specify measuring range and output signal in plain text.
