Data sheet 902044 Page 2/8
2014-05-16/00534480
JUMO GmbH & Co. KG Telefon: +49 661 6003-722/724
Hausadresse: Moritz-Juchheim-Straße 1, 36039 Fulda, Germany Telefax: +49 661 6003-601/688
Lieferadresse: Mackenrodtstraße 14, 36039 Fulda, Germany E-Mail: [email protected]
Postadresse: 36035 Fulda, Germany Internet: www.jumo.net
Technical data
Approvals/approval marks
Transmitter Input
Measuring input
Pt100 acc. to DIN EN 60751
Measuring range limits -50 to +260 °C
Measuring span 25 to 310 K (also see zero offset)
Zero offset
Data sheet 707030, page 7/10 For measuring spans < 75 K, fixed zero adjustment:
-40 °C, -20 °C, 0 °C, 20 °C, and 40 °C
For measuring spans
≥ 75 K: ±50 °C
Sensor current ≤ 0.5 mA
Sampling rate Permanent measurement due to analog signal path
Measuring circuit monitoring
Underrange
Dropping to ≤ 3.6 mA
Overrange Increasing to ≥ 22 mA to < 28 mA (typical 24 mA)
Probe short circuit ≤ 3.6 mA
Probe/cable break Positive: ≥ 22 mA to < 28 mA (typical 24 mA)
Output
Output signal
Load-independent direct current: 4 to 20 mA
Transmission behavior Temperature-linear
Transmission accuracy ≤ ±0.1%
Attenuation of the residual ripple
of a voltage supply of 24 V,
amplitude 10 V at 50 Hz,
burden 470
Ω at load of 10 M Ω
40 dB
Load (Rb) Rb = (Ub - 7.5 V) ÷ 22 mA
Load error ≤ ±0.02% per 100 Ω a
a All specifications refer to the measuring range end value of 20 mA.
Setting time for temperature changes ≤ 10 ms
Calibration conditions DC 24 V at approx. 22 °C
Calibration accuracy ≤ ±0.2% a, b or ≤ ±0.2 K
b The higher value is valid.
Overall accuracy, probe/calibration ±0.4 K (typical) at 20 °C and DC 24 V voltage supply
Voltage supply
Voltage supply (Ub)
DC 7.5 to 30 V
Reverse voltage protection Yes
Voltage supply influence ≤ ±0.01% per V deviation from DC 24 V a
Environmental influences
Operating temperature range
-40 to +85 °C
Storage temperature range -40 to +100 °C
Temperature influence ≤ ±0.01% per K deviation from 22 °C a
Resistance to climatic conditions similar to
DIN EN 60654 class D1 Relative humidity ≤ 95% annual average, no condensation
EMC EN 61326
- Interference emission Class B
- Interference immunity Industrial requirements
Approval
mark Testing agency Certificates/certification
numbers Inspection basis valid for
GL Germanischer Lloyd 15 700 - 00 HH Guidelines for the Performance of
Type Approvals Chapter 2,
Edition 2003 Basic type 902044/20 ...
Basic type 902044/21 ...
