Data Sheet 608501

Page 2/7

Technical data

Housing or bezel

black plastic;

steel housing (extra code 415)

Protection

front: IP53 to EN 60 529

rear: IP00 to EN 60 529 (IP54 with extra code 426)

Scale

white, black lettering

Accuracy class

Class 2 to EN 13190

Measuring system

liquid-filled

gas-filled

indication range

≤ 350 °C

indication range

≥ 400 °C

Time constant
t

0.632

approx. 12 sec, measured in water bath,

with a 6 mm dia. copper probe

approx. 4 sec, measured in oil bath,

with a 10 mm dia. stainless steel probe

Ambient temperature
error effect

in % of indication range (referred to the deviation from the reference value +23 °C)

on housing

0.15% of indication range

per °C change in ambient temperature

0.05% of indication range

per °C change in ambient temperature

on capillary (per meter)

0.03% of indication range

per °C change in ambient temperature

no effect

higher ambient temperature – higher temperature indication – lower switching point

standard

extra code (TZ) 651

extra code (TZ) 650

Electrical contact
Contact type

single-pole microswitch with a mechanically operated changeover contact

Contact rating

230 V AC +10/-15%, 48 — 63 Hz, p.f. = 1 (0.6)

5 (1.5) A

3 (1) A

10 (3) A

Switching differential

approx. 2% of indication range

2 to 4% of indication range

Switching point accuracy

± 0.5% of indication range referred to the switch-off point with rising temperature

Switching reliability

To ensure maximum switching reliability, we recommend a minimum voltage of 24 V and a

minimum current of 100 mA.

standard

extra code (TZ) 507

Electrical connection

faston connectors A 6.3 x 0.8 to DIN 46 244

screw terminals: for up to 1.5 mm

2

conductor cross-section

Setpoint adjustment

by setting device on window

Limit temperatures

for transport and storage: -20 to +70 °C

(for indication range -40 to +40 °C: up to 50 °C; for indication range -30 to +50 °C: up to 60 °C)

Nominal position

unrestricted

Note:
Physical and toxic features of the expansion means, which could emerge in the event of a measuring system break.

1)

There is currently no statement by the health authority concerning hazards to health in the event of short-term exposure and low concentration, e.g. measuring

system

break.

Control range with

scale limit value

Hazardous re-

actions

Fire and explosion hazard

hazardous to

waters

Information about toxicology

Ignition tem-

perature

Explosion limit

irritant

dangerous to

health

toxic

<

+200 °C

no

+ 355 °C

0,6 - 8 V%

yes

yes

1)

no

200 °C

≤ +350 °C

+ 490 °C

- -

yes

yes

1)

> 350 °C ≤ +500 °C

no

no

no

no

no
