Technical data
Display range (AB)
Display range in °C
Measuring range in °C
Tolerance in °C
469
-40...+40
-30...+30
1.5
566
-30...+50
-20...+40
1.5
643
-20...+120
-20...+100
3.0
807
0...+60
+10...+50
1.5
810
0...+80
+10...+70
1.5
814
0...+100
+10...+90
1.5
818
0...+120
+20...+100
3.0
826
0...+160
+20...+140
3.0
832
0...+200
+20...+180
3.0
834
0...+250
+30...+220
4.0
926
+50...+250
+70...+230
3.0
840
0...+300
+30...+270
6.0
927
+50...+300
+80...+270
4.0
843
0...+350
+50...+300
6.0
932
+50...+350
+80...+320
6.0
848
0...+400
+50...+350
6.0
851
0...+450
+50...+400
6.0
854
0...+500
+50...+450
8.0
858
0...+600
+100...+500
10.0
Liquid filling
Gas filling
Measuring system
Display range (AB)
≤ 350°C
Display range (AB)
÷ 400°C
Time behavior
approx. 12 s, measured in water,
with a probe Ø of 6 mm made of Cu.
approx. 4 s, measured in oil,
with a probe Ø of 10 mm made of stainless steel.
Ambient temperature
influence effect
In % of the display range (referring to the deviation from the reference value +23°C)
on case
0.15% of the display range
per K ambient temperature change
0.05% of the display range
per K ambient temperature change
on capillary (per m)
0.03% of the display range
per K ambient temperature change
no influence
Higher ambient temperature – higher temperature display – lower switching point
standard
Extra code (TZ) 650
Electric contact
Single-pole microswitch with mechanically actuate change-over contact
Type of contact
Contact rating
AC 230 V, +10/-15 %, 48 to 63 Hz, cos
ϕ = 1 (0.6)
5 (1.5) A
10 (3) A
Hysteresis
approx. 1.5% of the display range
1.5 to 3 % of the display range
Switching point accuracy
± 0.5% of the display range referring to the switch-off point with rising temperature
Switching reliability
To ensure a high switching reliability, we recommend a minimum voltage of
24 V and a minimum current of 100 mA
Electrical connection
Connection inlet: Cable cross section up to 2.5 mm
2
, suitable for cable-Ø from 6.5 to 13 mm
Note
Physical and toxic features of the expansion means, which could emerge in the event of a measuring system break.
Control range
with scale limit value
Hazardous
reactions
Fire and explosion hazard
hazardous to
waters
Information about toxicology
Ignition
temperature
Explosion
limit
irritant
dangerous to
health
toxic
≤ +200°C
no
+355°C
0.6 - 8V%
Yes
Yes
a
a
There is currently no statement by the health authority concerning hazards to health in the event of short-term exposure and low concentration, e.g. measuring
system break.
no
≥ +200°C ≤ +350°C
+490°C
- -
>
+350°C
≤ +500°C
no
0.6 - 8V%
no
no
no
