Data Sheet 608540

2011-08-01/00485270

Page 6/7

JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14

36039 Fulda, Germany

Postal address:

36035 Fulda, Germany

Phone:

+49 661 6003-0

Fax:

+49 661 6003-607

E-mail:

[email protected]

Internet:

www.jumo.net

JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:

+44 1279 635262

E-mail:

[email protected]

Internet: www.jumo.co.uk

JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866

1-800-554-5866

Fax:

315-437-5860

E-mail:

[email protected]

Internet: www.jumousa.com

Order details:

Industrial version

Contact thermometer, type 608540

Order code

(6)

Process connection (PA)

1

750

TF 01; temperature probe with stepped support tube

752

TF 11; temperature probe without support tube

843

TA 02; immersion tube with union nut and loose nipple

2

161

TA 03; immersion tube with loose union nut

847

TA 06; sliding clamp fitting on support tube

2

311

TA 20; immersion tube with loose nipple and shoulder

2

872

TA 21; immersion tube with loose plug and conical seal

873

TA 22; immersion tube with loose plug, conical seal and loose nipple

2

401

TA 23; immersion tube with plug and spring clip

874

TA 24; Immersion tube (CrNi) with screw connection (CuZn),

O ring sealing and clamping screw

2,5

913

SH 07; screw-in pocket, assembled, with clamping clip and fixing screw

2

SH 09;

(with TF 01)

1)

820

SH 09; weld-in pocket, assembled, with clamping clip and fixing screw

SH 09;

(not with FL21 - welding shoulder with steel 1.4515) (with TF 01)

876

SH10; screw-in pocket, assembled

2

871

SH11; screw-in pocket, assembled

2

(7)

Diameter of process connection (PA)

1

6

0

6 mm dia.

8

0

8 mm dia.

10

10 mm dia.

12

12 mm dia.

(8)

Thread for process connection (PA)

1

000

no thread (with TF 01 and TF 11)

103

G

3

/

8

(

3

/

8

" pipe) thread

104

G

1

/

2

(

1

/

2

" pipe) thread

105

G

3

/

4

(

3

/

4

" pipe) thread

106

G1 (1" pipe) thread

114

M 10 x 1 thread (with TA 23 and SH 11 only)
