Data Sheet 603031
2013-03-08/00309799
Page 2/6
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone: +49 661 6003-0
Fax: +49 661 6003-607
E-mail: [email protected]
Internet: www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
E-mail: [email protected]
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax: 315-437-5860
E-mail: [email protected]
Internet: www.jumousa.com
Technical data
Control ranges and temperature probes
Capillary and temperature probe
Electrical data
Type Control /
limit value ranges
in °C
max. admissible
excessive probe tem-
perature
in °C
Length of the temperature probe in mm
Copper (Cu) Stainless steel (CrNi)
ш 6 ш 8 ш 6 ш 8
ATH.-SE-2 0 0 to 100
20 to 0 90
30 to 110
20 to 120
60 to 140
20 to 150
50 to 200
50 to 250
50 to 300
125
125
135
140
165
175
230
290
345 107
138
125
107
123
88
101
-
-
75
91
84
75
83
65
72
-
-
99
130
117
99
117
80
93
73
63
67
83
76
67
76
57
64
54
49
ATH.-SE-20
ATH.-SE-70 30 to 110
60 to 140
20 to 150
50 to 250
50 to 300 135
165
175
290
345 112
110
80
-
-
78
77
61
-
-
104
102
72
66
58
70
68
53
50
-
Type Scale limit value Capillary Temperature sensor Remarks
ATH.-SE-2
ATH.-SE-20
ATH.-SE-70
≤ 200 °C
Copper (Cu)
ø 1.5mm
Material No. 2.0090
Copper (Cu)
Material No. 2.0090
hard soldered
–
> 200 °C
Copper (Cu)
ø 1.5mm
Material No. 2.0090
Stainless steel (CrNi)
Material No. 1.4571
hard soldered
–
all areas
Stainless steel (CrNi)
ø 1.5mm
Stainless steel (CrNi)
Material No. 1.4571
welded
against surcharge
Capillary length 1000 mm, max. 2000 mm as standard
min. bending radius
of the capillary
5 mm
Switching element ATH.-SE-2
ATH.-SE-20 ATH.-SE-70 ATH.-SE-70/574
Microswitch
with change-over contact
Microswitch
with N/C contact
and restart lock
Microswitch with N/C contact, re-
start lock and
additional signal contact
max. contact rating AC 230 V +10%, 10(2) A, cos ϕ = 1(0.6)
DC 230 V +10 %, 0.25 A
with a hysteresis of 1.5%:
AC 230 V +10%, 6(1.2) A, cos
ϕ = 1(0.6)
