Stock versions
Order details
Explosion protected surface-mounting thermostat, type series ATH-Ex-..
Part no. Type Control range °C Measuring system
material
Capillary mm Probe ø×length mm
60001242 ATH-Ex-2 –20...+50
CrNi 2000
6×153
60001243 ATH-Ex-2 0...+50 6×202
60001244 ATH-Ex-2 +40...+120 6×135
60001246 ATH-Ex-2 +50...+300 6×67
60001247 ATH-Ex-20 +40...+120 6×117
60001248 ATH-Ex-20 +50...+300 6×60
Order
code
( 1 ) Basic type
605041 Surface-mounting thermostat for explosive areas, type series ATH-Ex
( 2 ) Basic type extensions
02 ATH-Ex-2 Temperature monitor TW
20 ATH-Ex-20 Fail-safe temperature monitor STW
( 3 ) Control/limit value ranges °C
014 -20...+50
021 0...+50
025 0...+100
056 +40...+120
062 +50...+200
080 +80...+250
064 +50...+300
045 +20...+400
046 +20...+500
( 4 ) Capillary length
1000 1,000 mm
2000 2,000 mm
3000 3,000 mm
4000 4,000 mm
5000 5,000 mm
. . . . (special length, specifications in plain text in mm)
( 5 ) Capillary material
20 CrNi Stainless steel (1.4571)
40 Cu Copper tin-plated (only possible up to 200°C)
( 6 ) Process connection (PC)
10 plain cylindrical probe (standard)
20 Screw-in sleeve
( 7 ) Thread of process connection
00 without thread (process connection 10)
13 External thread G 1/2
