Technical data
Switching function
Temperature monitor TW
and fail-safe proof temperature monitor STW
Self-monitoring
for the fail-safe temperature monitor STW
If the temperature exceeds the setpoint value set on the temperature
probe, the microswitch will be tripped by the transmission mechanics
and the current circuit opened or closed.
The microswitch is reset to its original status once the setpoint value
set is gone below (by the hysteresis).
If the measuring system is destroyed, i.e. if the expansion fluid
emerges, the pressure in the STW diaphragm drops and permanently
opens the current circuit. Unlocking is no longer possible.
If the probe has cooled down to a temperature within the control
range table, e.g. below -20°C, the current circuit is also opened. The
STW is automatically restarted.
Control ranges and probe table
Control
range
Switching point accuracy in the
upper third of the scale range
a
a.
Offset of the switching point accuracy to a different scale range is possible upon customer request.
maximum
capillary length
maximum probe
temperature as per
DIN EN 14597
STW opens at
probe
temperature
Probe length "L"
with "d“ = 6 mm
in °C
TW
STW
in mm
in °C
below °C
TW
STW
-20...+50
+0 K
-3 K
+0 K
-3.5 K
5000
+60
-30
153
132
0...+50
+0 K
-2 K
+0 K
-2.5 K
+60
-10
202
172
0...+100
+0 K
-4 K
+0 K
-5 K
+115
117
102
+40...+120
+0 K
-3 K
+0 K
-4 K
+140
135
117
+50...+200
+0 K
-6 K
+0 K
-8 K
+230
107
94
+80...+250
+0 K
-7 K
+0 K
-8.5 K
+300
-20
90
78
+50...+300
+0 K
-10 K
+0 K
-12.5 K
+345
-30
67
60
+20...+400
+0 K
-15 K
+0 K
-19 K
1000
+460
-30
- -
202
+20...+500
+0 K
-19 K
+0 K
-24 K
2000
+550
-30
237
149
Capillary and temperature probe
Type
End of scale
Capillary
∅ 1.5 mm
Temperature probe
ATH-Ex-..
up to 200°C
Copper (Cu)
Material No. 2.0090
electrically tin-plated
Copper (Cu)
Material No. 2.0090
hard soldered,
electrically tin-plated
up to 300°C
Stainless steel (CrNi)
Material No. 1.4571
Stainless steel (CrNi)
Material No. 1.4571,
welded
up to 500°C
Stainless steel (CrNi)
Material No. 1.4571
Stainless steel (CrNi)
Material No. 1.4571,
welded
capillary length
standard 1000 mm, maximum 5000 mm
min. bending radius of
capillary
5 mm
Electrical data
Switching element
pressure-resistant encapsulated microswitch with change-over contact
maximum contact rating
AC 230 V +10%, 5 A, cos
ϕ ≥ 0.9
Electrical connection
Screw-connection in a case, suitable for a cable cross section up to 2.5 mm
2
