JUMO 60.2026 Panel-mounting thermostat, EM Data Sheet User Manual
Page 7
2013-06-20/00073209
Data Sheet 602026
Page 7/7
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address:
36035 Fulda, Germany
Phone:
+49 661 6003-0
Fax:
+49 661 6003-607
E-mail:
Internet:
www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
E-mail:
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax:
315-437-5860
E-mail:
Internet: www.jumousa.com
(9)
Material of process connection
00
Only with process connection "10"
46
CuZn
(Brass)
20
CrNi
(Stainless steel 1.4571)
(10)
Fitting length "S" (immersion tube length)
000
Without thermowell
100
100 mm
120
120 mm
150
150 mm
200
200 mm
300
300 mm
...
(Special length, specification in mm)
(11)
Diameter "D" (immersion tube diameter)
00
Without thermowell
8
8 mm
(12)
Diameter "d" (probe diameter)
00
Without thermowell
6
6 mm
(13)
Extra codes
000
Without extra codes
574
"U"
Microswitch with N/C contact, restart lock, and additional signal contact (only STB)
702
"au"
Snap-action switch with gold plating (cannot be combined with extra code "574")
699
"X"
Screw-connection with 2.5 mm
2
conductor cross section
704
"b1"
Switching head mounting with 2 M4 screws, spaced 28 mm
705
"b2"
Switching head mounting with 2 M3 screws, spaced 33 mm
706
"b3"
Switching head mounting with 2 M3 screws, spaced 22 mm
710
"b7"
Central mounting with acorn nut (only for STB)
707
"TK"
Temperature compensation
a
Different control / limit ranges upon request
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
Order code
602026 /
-
-
-
-
-
-
-
-
-
-
/
,
...
Order example
602026 /
80
- 000 - 120 -
2000
-
40
-
10
-
00
-
00
-
000
-
00
-
00
/ 000
a
a
State extra codes one after another, separated by commas
,
...
