Admissible load at the sheath
Sheaths
20 (U), 22 (US), 30 (UZ), 32 (UZS),
40 (E), 41 (ES), 45 (EZS) and 46 (EZS)
The following values describe the maximum capacity of the corresponding connection type.
The maximum pressure sealable depends on the fitting conditions and may be lower.
Sheath made of steel 22, 23, 32, 41, 42, 45 and 46
(Discontinued types: 20, 30, 32 and 40)
Sheath made of stainless steel
Sheath made of brass
Material
Tube
Screw-in nipples
Welding nipples
St 35.8 I
Steel 1.0038
Steel 1.5415
Capacity
Temperature
Pipe diameter
8 x 0.75 mm or conical
10 x 0.75 mm
15 x 0.75 mm
Maximum admissible pressure
100°C
89 bar
72 bar
48 bar
150°C
83 bar
67 bar
45 bar
200°C
78 bar
63 bar
42 bar
300°C
59 bar
47 bar
32 bar
350°C
50 bar
40 bar
27 bar
max. admissible
operating
temperature
Tube
Nipple
max. admissible operating temperature*
static load
without load
St 35.8 I
Screw-in nipples
+300°C
+530°C
Welding nipples
+450°C
* observe the max. admissible probe temperature of the respective thermostat version.
*
For operating temperatures > +420°C: observe the operating life of 200,000 h at a static load TRD508.
*
Sheath "21" (UO) and "31" (UZO): Use only in pressureless medium.
Material
Pipe and nipple: Stainless steel (1.4571)
Capacity
Temperature
Pipe diameter
8 x 0.75 mm or conical
10 x 0.75 mm
15 x 0.75 mm
Maximum admissible pressure
100°C
92 bar
74 bar
50 bar
150°C
88 bar
71 bar
48 bar
200°C
83 bar
67 bar
45 bar
300°C
72 bar
58 bar
39 bar
400°C
67 bar
54 bar
36 bar
max. admissible
operating
temperature*
static load +400°C
without load +530°C
* observe the max. admissible probe temperature of the respective thermostat version.
Material
Pipe and nipple: CuZn, nickel plated
Capacity
Temperature
Pipe diameter
8 x 0.75 mm
10 x 0.75 mm
15 x 0.75 mm
Maximum admissible pressure
100°C
50 bar
40 bar
27 bar
150°C
48 bar
39 bar
26 bar
max. admissible
operating
temperature*
+150°C
* observe the max. admissible probe temperature of the respective thermostat version.
