2011-07-01/00073261
Page 7/8
Sheaths
Order code: 1 2 3 4 5
Process connection Thread G Material
Immersion tube
length "S" in mm
Immersion tube Ø
in mm
Welding sleeve for
union nut (52)
with intermediate
piece, conical
"46“
(EZS)
without thread
32
St (S
tee
l)
CrN
i (
s
ta
in
le
ss
s
tee
l) 100
120
150
200
300
400
Specifications
in plain text
Immersion tube coni-
cal from 12 to 8 mm
(Internal Ø 6.5)
Order code: 606710-46 01 20 . . . 8
1 2 3 4 5
Order code: 606710-. . - . . - . . - . . . - . .
Order example: 606710- -
Optional accessories Abbreviation for
process connections
Part No.
Sheet steel flange 72 60/60677200
Wall support 73 60/60171300
Holder
78
60/00558731
3 pieces
79
60/00558730
6 pieces
S
Ш
12 Ш
90 Ш
~1
15
Ш 30
