10 Web server
80
Navigation
Individual pages can be brought up by clicking (left mouse button).
Visualization
area
The visualization area shows current data for the paperless recorder. The most
recent data are read from the device automatically every 3 seconds.
Online visualization
v Chapter 10.2
Configurable device name;
read automatically
Three freely programmable HTML
pages; created with the setup
program
v Chapter 10.3
Online visualization of
current batch reports
v Chapter 10.4
Start of QuadView
Configuration of QuadView
v Chapter 10.5
