Connection diagram circuit variants – JUMO 709020 TYA-432 thyristor power switch Data Sheet User Manual
Page 4
JUMO GmbH & Co. KG 36035 Fulda, Germany
2009-01-01/00073742
Data sheet 70.9020
Page 4/5
Connection diagram
Circuit variants
TYA 432-100/45, 660
TYA 432-100/30, 265 (660)
1 pole solid state relay in a
1 phase application phase neutral
conductor, phase phase
Two 1 pole solid state relays in a
3 phase application delta and star
(low power consumption)
Three 1 pole solid state relays in a
3 phase application delta, star,
star with zero conductor
