44. RESTORE
Restore parameters saved in the EEPROM memory module.
All of the configuration setting parameters can be restored from the EEPROM
memory module if they have been inadvertently changed or corrupted. This feature
can also be used to load configuration setting parameters into a different or new
control module. This reduces the configuration time for multi-system applications that
require similar settings or when a replacement control module is required.
Press EXECUTE to enter the menu.
DISABLED
This menu is disabled for inadvertent use. Proceed to enable.
ENABLED
Press and hold MENU (
) and MENU (
) at the same time for 4-5 seconds.
MEMCHECK
Automatically checks the EEPROM memory module for parameter type.
OKAY....
The EEPROM memory module has been verified for parameter type.
PROCEED?
Press EXECUTE to proceed.
SURE ???
Press EXECUTE to proceed.
CRC-TEST
Automatically does a CRC test on the parameter code in the EEPROM.
WAIT
CRC test in progress.
VERIFY
CRC test in progress.
DONE!!
CRC test is done and the parameter restore automatically begins.
WILL
Parameter restore in progress.
AUTO
Parameter restore in progress.
RESTART
When parameter restore is complete, the system restarts.
SERIAL #
Displayed when the silicone serial number on the EEPROM memory module is a
mismatch with the silicone serial number on the MADD-96 microcontroller.
PROCEED?
Press EXECUTE to proceed.
NO MEM!
Displayed if an EEPROM memory module is not detected.
WRONG
Displayed if the wrong type (parameter) of EEPROM memory module detected.
MEM TYPE
Displayed if the wrong type (parameter) of EEPROM memory module detected.
WRONG
Displayed if the wrong product type of EEPROM memory module detected.
PRODUCT
Displayed if the wrong product type of EEPROM memory module detected.
ERROR
Displayed when an error occurs. Waits for key press to restart RESTORE.
45. BACKUP
Backup parameters and save them in the EEPROM memory module.
All of the configuration setting parameters can be saved in the EEPROM memory
module for backup. The backup parameters can then be restored if they have been
inadvertently changed or corrupted. Once backup is complete the EEPROM memory
module may be removed for safe storage. All DE90-3000 Series retrofit control
systems are shipped with the factory default settings saved in the EEPROM memory
module.
Press EXECUTE to enter the menu.
DISABLED
This menu is disabled for inadvertent use. Proceed to enable.
ENABLED
Press and hold MENU (
) and MENU (
) at the same time for 4-5 seconds.
MEMCHECK
Automatically checks the EEPROM memory module for parameter type.
SURE ???
Press EXECUTE to proceed.
WAIT
Automatically begins parameter backup and generates CRC value.
VERIFY
Automatically verifies parameter backup data and CRC value.
DONE!!
Parameter backup is done and saved in the EEPROM memory module.
NO MEM!
Displayed if an EEPROM memory module is not detected.
WRONG
Displayed if the wrong type (parameter) of EEPROM memory module detected.
MEM TYPE
Displayed if the wrong type (parameter) of EEPROM memory module detected.
WRONG
Displayed if the wrong product type of EEPROM memory module detected.
PRODUCT
Displayed if the wrong product type of EEPROM memory module detected.
DATA ERR
Displayed when a data error occurs. Waits for key press to restart BACKUP.
NOTE: Backup all DE90-3000 Series retrofit control systems when configuration is
complete.
