Warranty
The DE90-3000 comes with a standard one (1) year limited warranty.
Extended warranties of up to ten (10) years are available at the time of
purchase.
For details visit www.johnsonsystems.com/warranties.htm
For Technical Assistance
1. Refer to your product user manual. The most current revision is
available online: www.johnsonsystems.com/literature.htm
2. Contact the “point-of-sale” dealer or distributor from which this product
was originally purchased, and ask for technical assistance.
3. If neither of the above can provide you with the necessary information,
please contact our factory via email ([email protected])
or phone (403-287-8003) during business hours (Monday to Friday,
8:00AM to 5:00PM MST).
Contents
Warranty ..........................................................................................................2
Introduction ......................................................................................................3
Packaging & Contents .....................................................................................4
Installation .......................................................................................................4
DE90-3000 Backplane...................................................................................13
DE90-3000 Front Panel (Faceplate)..............................................................14
Control Input/Output Connections .................................................................15
MADD-24 (Multiple Application Dimmer Driver) ............................................17
User Interface ................................................................................................18
System Status - LED Indicators.....................................................................19
System Status - LCD Display ........................................................................19
Quick Programming Reference to System Configuration Menu Items ..........21
Detailed Programming of System Configuration Menu Items........................22
Important Hard-key Information .....................................................................38
Troubleshooting Reference ...........................................................................39
