3 Object Structure
3.1 Identity Object (Class Code 01
hex
)
Class Code: 1 (01
hex
)
Class Attributes: None
Instance Attributes
Attribut ID Access Rule Name Description
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
1 (01
hex
) get INFICON Vendor Identification
Vendor ID: 144dez.
2 (02
hex
) get Generic Device Device Type
3 (03
hex
) get Product Code Vendor Productcode
4 (04
hex
) get Revision DeviceNet Software Version-Number
5 (05
hex
) get Status Device Status
6 (06
hex
) get Serial Number
7 (07
hex
) get Product Name PEG100-D
Services
Service Code Name
––––––––––––––––––––––––––––––
5 (05
hex
) Reset
14 (0E
hex
) Get Attribute Single
16 (10
hex
) Set Attribute Single
3.2 Device Manager(DM) Object (Class Code 64
hex
)
Class Code: 100 (64
hex
)
Class Attributes: None
Instance Attributes
Attribut ID Access Rule Name Data/Type Description
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
49 (31
hex
) get Device Type String [3] Device Typ SEMI "CIG" ;
43 49 47 Cold cathode ion gauge
50 (32
hex
) get Standard Revision String [5] "DRAFT"
Level 44 52 41 46 54
51 (33
hex
) get Device Manufacturer String [7] Vendor Identifikation
Identifier 4c 45 59 42 4f 4c 44 "INFICON"
52 (34
hex
) get Manufacturer Model String [5] Catalog Number
Number
53 (35
hex
) get Firmware Revision String [5] Software Version
Level 31 2e 30 30 30
54 (36
hex
) get Hardware Revision String [5] Hardware Version
Level 30 2e 30 30 30
