PRE-INSTALLATION CHECKLIST
Micro GC Fusion
Pre-Installation Checlist
PN 074-615-P1A
3 of 5
Sample Gas Pressure Range
CAUTION
Sample gas pressure greater than 172 kPa (25 psi) will
damage Micro GC Fusion.
 . . . .Maximum pressure for direct sample injection into either the front or rear sample
inlet is 172 kPa (25 psi). To prevent damage to Micro GC Fusion, limit input
sample pressure to 69 kPa (10 psi) or lower.
 . . . .When the Integrated Sample Conditioner is installed, sample pressures up to
6,895 kPa (1,000 psi) can be introduced into either the front or rear sample inlet.
Sample pressures higher than 6895 kPa (1,000 psi) must be reduced.
 . . . .When a Genie Filter Assembly (PN 952-022-G1) is installed, sample pressures
up to 3447 kPa (500 psi) can be introduced into either the front or rear sample
inlet. Sample pressures higher than 3447 kPa (500 psi) must be reduced.
Installation Space and Venting
 . . . .Micro GC Fusion 2-Module instrument
Dimension (L x W x H): 43.3 x 20 x 26.5 cm (17 x 7.9 x 10.4 in.)
Weight: 6.8 kg (11 lb.)
 . . . .Install Micro GC Fusion in a location with easy access to the instrument and
associated computer.
 . . . .For optimum Micro GC Fusion performance and to dissipate heat, do not restrict
the airflow around Micro GC Fusion.
WARNING
Safely vent sample streams—potentially toxic, noxious, or
flammable gases—outside the instrument and away from
the operating area. Vent toxic gases to a fume hood,
chemical trap, or reaction medium.
 . . . .Avoid venting Micro GC Fusion into drafty areas, such as in front of a
heating/cooling vent.
