PRE-INSTALLATION CHECKLIST
Micro GC Fusion
Pre-Installation Checlist
PN 074-615-P1A
1 of 5
Site Preparation
Proper site preparation prior to installing Micro GC Fusion is very important.
Contact INFICON (
www.inficon.com ) with any questions regarding site preparation.
NOTE: Checkboxes () identify hardware and actions that must be addressed when
installing Micro GC Fusion.
List of Required Tools
 1 1/8" wrench recommended, or adjustable large wrench
(for attaching regulator to gas tank)
 Teflon ® tape for regulator connections
NOTE: The following tools are included in the optional Install Kit (PN 952-021-G1).

Open-ended wrench, 1/4 in. and 5/16 in.
 Open-ended wrench, 7/16 in. and 9/16 in.
 Open-ended wrench, 3/8 in. and 7/16 in.
 Hex driver, 2.5 mm ball-point long shank
 Tubing cutter
Carrier Gas
 . . . .Carrier gas (e.g., helium, argon) purity of 99.999%, or minimum 99.995%
when the appropriate carrier gas trap is installed. Contact INFICON for
carrier gas trap assistance.
NOTE: A pressurized [>16,547 kPa (>2,400 psi)] 50 liter tank of carrier gas will
last approximately one year or more.
 . . . .Dual Stage Regulator for pressurized carrier gas tank with outlet pressure
regulated to 400-427 kPa (58-62 psi). A Swagelok 1/8 in. fitting is preferred on
the regulator outlet to connect the carrier gas feed tube to Micro GC Fusion.
NOTE: In North America, use the CGA 580 inlet connection (PN 952-416-P1)
for helium, nitrogen and argon carrier gas. Use the CGA 350 inlet
connection (PN 952-415-P1) for hydrogen carrier gas. For installations
outside of North America, use the appropriate inlet connections as
standard for the region.
CAUTION
Exceeding 427 kPa (62 psi) carrier gas pressure may result
in instrument damage.
