10. Use flexible transition between rigid ductwork and unit to
prevent transmission of vibration. The transition may be
screwed or bolted to duct flanges. Use suitable gaskets to
ensure weathertight and airtight seal.
11. All units must have field-supplied filters or accessory filter
rack installed in the return-air side of the unit. Recom-
mended sizes for filters are shown in Tables 1 and 2.
12. Size all ductwork for maximum required airflow (either
heating or cooling) for unit being installed. Avoid abrupt
duct size increases or decreases or performance may be
affected.
13. Adequately insulate and weatherproof all ductwork located
outdoors. Insulate ducts passing through unconditioned
space, and use vapor barrier in accordance with latest issue
of Sheet Metal and Air Conditioning Contractors National
Association (SMACNA) and Air Conditioning Contractors
of America (ACCA) minimum installation standards for
heating and air conditioning systems. Secure all ducts to
building structure.
14. Flash, weatherproof, and vibration-isolate all openings in
building structure in accordance with local codes and good
building practices.
TABLE 1—PHYSICAL DATA—UNIT 701A
UNIT SIZE
030
036
042
048
060
NOMINAL CAPACITY (ton)
2-1/2
3
3-1/2
4
5
OPERATING WEIGHT (lb.)
258
268
294
324
389
COMPRESSOR
Reciprocating
Scroll
Reciprocating
REFRIGERANT (R-22)
Quantity (lb.)
3.65
4.4
6.4
5.1
7.4
REFRIGERANT METERING DEVICE
Orifice ID (in.)
AccuRater®
.034
.032
.034
.032
.030
CONDENSER COIL
Rows...Fins/in.
Face Area (sq. ft.)
1...17
9.1
1...17
10.9
1...17
9.1
1...17
12.3
2...17
12.3
CONDENSER FAN
Nominal Cfm
Diameter
Motor Hp (Rpm)
2400
22
1/8 (825)
3000
18
1/4 (1100)
3000
22
1/4 (1100)
3600
22
1/4 (1100)
3600
22
1/4 (1100)
EVAPORATOR COIL
Rows...Fins/in.
Face Area (sq. ft.)
2...15
3.7
3...15
3.06
4...15
3.06
3...15
4.7
4...15
4.7
EVAPORATOR BLOWER
Nominal Airflow (Cfm)
Size (in.)
Motor Hp (RPM)
1000
10x10
1/4 (1075)
1200
11x10
1/2 (1075)
1400
11x10
3/4 (1075)
1600
11x10
3/4 (1075)
2000
11x10
1.0 (1100)
RETURN-AIR FILTERS (in.)*
Throwaway
20x20
20x24
20x24
24x30
24x30
* Required filter sizes shown are based on the larger of the ARI (Air Conditioning and Refrigeration Institute) rated cooling airflow or the heating airflow velocity of 300 ft./min.
for throwaway type or 450 ft./min. for high-capacity type. Air filter pressure drop for non-standard filters must not exceed 0.08 in. wg.
TABLE 2—PHYSICAL DATA—UNIT 702A
UNIT SIZE
030
036
042
048
060
NOMINAL CAPACITY (ton)
2-1/2
3
3-1/2
4
5
OPERATING WEIGHT (lb.)
291
299
321
326
399
COMPRESSOR
Scroll
REFRIGERANT (R-22)
Quantity (lb.)
4.4
5.2
7.6
8.3
8.1
REFRIGERANT METERING DEVICE
Orifice ID (in.)
AccuRater®
.030
.032
.034
.034
.032
CONDENSER COIL
Rows...Fins/in.
Face Area (sq. ft.)
1...17
12.7
2...17
9.1
2...17
9.1
2...17
12.3
2...17
16.4
CONDENSER FAN
Nominal Cfm
Diameter (in.)
Motor Hp (Rpm)
2350
22
1/8 (825)
2350
22
1/8 (825)
3300
22
1/4 (1100)
3300
22
1/4 (1100)
3300
22
1/4 (1100)
EVAPORATOR COIL
Rows...Fins/in.
Face Area (sq. ft.)
3...15
3.1
3...15
3.7
3...15
4.7
4...15
4.7
4...15
4.7
EVAPORATOR BLOWER
Nominal Airflow (Cfm)
Size (in.)
Motor Hp (RPM)
1000
10x10
1/4 (1075)
1200
11x10
1/2 (1075)
1400
11x10
3/4 (1075)
1600
11x10
3/4 (1075)
1750
11x10
1.0 (1040)
RETURN-AIR FILTERS (in.)*
Throwaway
20x20
20x24
20x30
24x30
24x30
*
Required filter sizes shown are based on the larger of the ARI (Air Conditioning and Refrigeration Institute) rated cooling airflow or the heating airflow velocity of 300 ft./min.
for throwaway type or 450 ft./min. for high-capacity type. Air filter pressure drop for non-standard filters must not exceed 0.08 in. wg.
