HDA 5500 User Manual
- 9 -
Menu point Setting Setting range Default setting
Calibration of sensor zero point (CALi.)
The actual measurement is saved as the new zero
point. This is possible in the range +/- 2.5 % of the
display range.
is displayed if a calibration has been
carried out in the permitted range.
is displayed if a calibration has not
been possible.
The function is useful for example, if the output signal always
has an offset which should be displayed as the zero point.
Actual measured value is not to be saved.
YES
no no
Analogue output signal (ouT.M)
4..20 mA through analogue output signal
0..10 V through analogue output signal
MA
VoLT VoLT
Software version (VErS)
Display of the software version (for reference only)
To close basic settings (End)
Basic settings menu closes.
Changed settings are saved.
Basic settings can still be altered.
YES
no no
