12
E
TECHNICAL DATA
ROTACOOL circulating chiller
Operating temperature range
[°C] - 10 to + 40
Resolution/accuracy [K] 0.1 / 0.5
Temperature stability [K] +/- 0,5
Cooling performance in W at an
ambient temperature of 20°C at 15 °C 0.42 kW
at 0 °C 0.35 kW
at - 10 °C 0.22 kW
Cooling liquid capacity [I] 2
Refrigerant in the chiller (provided by manufacturer) R 134 a (CFC free) 0.18 kg
max. delivery (pressure) [l/min] 20
Delivery pressure (head) [bar] 0.2
max. delivery (suction) [l/min] 17
Delivery suction pressure (head) [bar] 0.18
Cooling liquid connection [mm] M 16 x 1 / NW 8/12
Material of the heat exchanger, pump and housing stainless steel 1.4301
Basic area (W x D) [mm] 470 x 580
Overall height/height of platform [mm] 420 / 95
Platform for rotary evaporator (W x D) [mm] 470 x 405
Mains voltage 230V/50Hz or 115V/60Hz
Power rating [W] 600
Weight [kg] 32
Protection class IP 20
Admissible ambient conditions 5 - 32 °C at 80% rel. Humidity
WARRANTY / EXCLUSION OF LIABILITY / COPYRIGHT
Warranty
Heidolph Instruments guarantees warranty that the present product shall be free from defects
in material (except wear parts) and workmanship for 3 years from the date shipped off the
manufacturer’s warehouse.
Transit damage is excluded from this warranty.
To obtain such warranty service, contact Heidolph Instruments or your local Heidolph
Instruments Dealer. If defects in material or workmanship are found, your item will be
repaired or replaced at no charge.
Misuse, abuse, neglect or improper installation are not covered by this warranty guarantee.
Alterations to the present warranty guarantee need Heidolph Instruments’ consent in writing.
Exclusion Clause
Heidolph Instruments cannot be held liable for damage from improper use or misuse.
Remedy for consequential damage is excluded.
Copyright
Copyright in pictures and wording of the present Instruction Manual is held by Heidolph
Instruments.
