Grayhill Pushbutton switches: Butt Contact 46 Series - Manual (Page 3)

Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
Pushbutton Switches
Butt Contact Pushbutton Switches
SerieS 30 and 46
decorator Line
FeatureS
• Attractive Front Panel Bezels (6
choices)
• Space-Saving: Only 11/16" Square
• SPST with Option of Positive Feel
• SPDT, DPDT with Momentary Contact
or Alternate Action
• Sturdy Metal Sleeve or Bushing and
Nut Provide Secure Mounting
CirCuitry
SPSt–normally Open SPdt–Break Before Make dPdt–Break Before Make
46-01-05-500-*
46-01-07-500-* 46-01-08-500-*
46-01-09-500-* 30-01-01-500-*
30-01-04-500-*
Momentary 46-01-08-500-*
Alt. Action
46-01-09-500-*
Partial
Part no.
Feature
Momentary 30-01-01-500-* .880 (22,35)
Pos. Feel 30-01-04-500-* 1.037 (26,34)
Partial
Part no.
Feature
dim.
a
diMenSiOnS in inches (and millimeters)
*Partial part number; complete part number by adding a dash for button color: white -01; red -03;
green -04; blue -05; yellow -06 or black -07, see Ordering Information.
Mounting Hardware
For 46-01-08-500 & 46-01-09-500
(See drawing above–mounting hardware shipped
loose.)
For SPSt & SPdt switches
One internal tooth lockwasher
One knurled ring nut .640 ± .010 (16,26 ± 0,25) DIA.
.094 ± .010 (2,39 ± 0,25) Thk.
FrOnt VieWS and MOuntinG
Momentary 46-01-05-500-* 1.174 (29,82)
Alt. Action
46-01-07-500-* 1.264 (32,11)
Partial
Part no.
Feature
dim.
a
Terminals are
marked on switch.
1/2-32 UN-2A
THREAD
.100 – .005
(2,54 – 0,13 )
.220 – .025
(5,59 – 0,64)
DIM. A
– .015 (0,38)
SEE CHART
.255 – .032
(6,48 – 0,81)
.093 – .005
(2,36 – 0,13)
.590 – .003
(14.99 – 0,08)
SQUARE WILL FIT
PANEL
.020 (0,51)
MIN. TO
.125 (3,18)
MAX.
LABEL*
*PART NUMBER
AND E.I.A. DATE
CODE LABEL
Terminals are marked on switch.
WILL FIT
PANEL
.020 (0,51)
MIN. TO
.125 (3,18)
MAX.
1/2-32 UN-2A
THREAD
DIM. A
– .015 (0,38)
SEE CHART
.255 – .032
(6,48 – 0,81)
.093 – .005
(2,36 – 0,13)
.590 – .003
(14.99 – 0,08)
SQUARE
NC
NO
C INSULATING
BARRIER
.150 – .010
(3,81 – 0,25)
.187 – .015
(4,75 –, 0,38)
LABEL*
*PART NUMBER
AND E.I.A. DATE
CODE LABEL
.150
– .010
(3,81
– 0,25)
1.194
– .031
(30,33
– 0,79)
.281 – .032
(7,14 – 0,81)
.093 – .010
(2,36 – 0,25)
.605 (15,37)
SQUARE MAX.
INSULATING BARRIER
WILL FIT PANEL
.010 (0,25) MIN.
TO .218 (5,54) MAX.
NC
NO
C
C
NC
NO
MOUNTING SLEEVE
.187 – .015
(4,75 – 0,38)
E.I.A. DATE
CODE LABEL
SPSt n.O. SPdt - BBM
n.C.
n.O.
C.
dPdt BBM
n.C.
n.O.
C1
n.C.
n.O.
C2
.485 ± .010
(12,32 ± 0,25)
.687
(17,45)
MAX.
.610 ± .004
(15,49 ± 0,02) Sq.
.610 ± .004
(15,49 ± 0,02)
Wide Slot .031 (0,79)
MAX. RADIUS
SINGLE STACKED
RECOMMENDED PANEL CUTOUT
FOR SQUARE BEZEL SWITCHES
Note: All switches fit panels up to .250 (6,35) thick.
Front and back panel access required for installation.
