Gast R7P - Manual (Page 10)

PARTS & ORDERING INFORMATION
REF# ITEM QTY R3105-12 R4110-2 R4P115 R5125-2 R6125-2 R6P335A R6135J-10
R3305A-13 R4310A-2 R4P315A† R5325A-2 R6150J-2 R6P350A
R4310B-1 R5325B-1 R6325A-2 R6P350B
R6335A-2
R6335B
R6350A-2
R6350B-2
1 COVER 1 AJ101C AJ101D AJ101L AJ101EQ AJ101FB AJ101K AJ101FB
2 LOCK NUT 1 BC181 BC181 BC181 AJ259 AJ259 AJ259 AJ259
3 IMPELLER 1 AJ102CA AJ102D AJ102L AJ102E AJ102FR AJ102K AJ102FR
4 SQUARE KEY 1 AB136A AB136D AB136D AB136 AB136 AB136 AB136
5 SHIM SPACER ∆ AJ109 AJ109 AJ109 AJ109 AJ109 AJ109 AJ260A
5 † SHIM SPACER † 1 – – AJ109A† – – – –
6 RETAINING RING 1 AJ149 AJ149 AJ149 – – – –
7 HOUSING 1 AJ103C AJ103DR AJ103L AJ103EQ AJ103FQ AJ103K AJ103FQ
8 MUFFLER BOX 1 – – – – – AJ104K –
9 SPRING 2 – AJ113DR AJ113DQ AJ113DQ AJ113FQ AJ113FQ AJ113FQ
9A SCREEN 2 – – AJ123EQ AJ123EQ AJ123FB – AJ123FB
10A FOAM ∆ AJ112C(4) AJ112DS(4) AJ112ER(6) AJ112ER(6) AJ112FC(6) AJ112K(8) AJ112FC(6)
10B FOAM 2 AJ112CQ AJ112DR – – – – –
11 MUFFLER EXTENSION 1 AJ106CQ AJ106DQ AJ106EQ AJ106EQ AJ106FR – AJ106FR
REF# ITEM QTY R6P350A R6P350B R6P355A R6PP3110M* R6PS3110M* R7100A-3 R7100B-1
1 COVER 1 AJ101K AJ101K AJ101KA AJ101KA(2) AJ101KA(2) AJ101G AJ101G
2 LOCK NUT/BOLT 1 AJ259 AJ259 BB750 BB750(2) BB750(2) BB750 BB750
3 IMPELLER 1 AJ102K AJ102K AJ102KA AJ102KA(2) AJ102KA(2) AJ102GZ AJ102GA
4 SQUARE KEY 1 AB136 AB136 AB136 AB136(2) AB136(2) AC628 AC628
5 SHIM SPACER ∆ AJ109 AJ169F AJ169F AJ169F AJ169F AJ110 AJ110
6 RETAINING RING 1 – – – – – – –
7 HOUSING 1 AJ103K AJ103K AJ103KA AJ103KD(2) AJ103KD(2) AJ103GA AJ103GA
8 MUFFLER BOX 1 AJ104K AJ104K AJ104K – – AJ104GA AJ104GA
8A SCREEN 2 – – – – – AJ998G AJ998G
9 SPRING 2 AJ113FQ AJ113FQ AJ113FQ – – – –
10A FOAM ∆ AJ112K(8) AJ112K (8) AJ112K (8) – – AJ112GA(8) AJ112GA(8)
10B FOAM 2 – – – – – – –
11 MUFFLER EXTENSION 1 – – – – – – –
12 ** O-RING 2 – – – AJ175 – –
13 GASKET 4 – – – AJ107F AJ107F – –
Please reference the exploded view on the next page for the following model and parts tables.
†
R4P315A only.
* Dual models.
** Not shown.
∆ As required.
Parts listed are for stock models. For specific OEM models, please consult the factory.
When corresponding or ordering parts, please give complete model and serial numbers. 10
REF# ITEM QTY R7P3180M* R7S3180M* R9P3300M* R9S3300M* R93150A
1 COVER 1 AJ101G(2) AJ101G(2) AJ101M(2) AJ101M(2) AJ101M
2 LOCK NUT/BOLT 1 BB750(2) BB750(2) BB707(2) BB707(2) BB707
3 IMPELLER 1 AJ102GZ(2) AJ102GZ(2) AJ102M(2) AJ102M(2) AJ102M
4 SQUARE KEY 1 AC628(2) AC628(2) AE130A(2) AE130A(2) AE130A
5 SHIM SPACER ∆ AJ110 AJ110 BJ110 BJ110 BJ110A
6 RETAINING RING 1 – – – – –
7 HOUSING 1 AJ103GA(2) AJ103GA(2) AJ103M(2) AJ103M(2) AJ103M
8 MUFFLER BOX 1 – – – – AJ104MP
8A SCREEN 2 – – – – AJ998M
9 SPRING 2 – – – – –
10A FOAM ∆ – – – – AJ112M(10)
10B FOAM 2 – – – – –
11 MUFFLER EXTENSION 1 – – – – –
12 ** O-RING 2 AJ175G – AJ175G – –
