Operating Instructions Safety Switch CET.-AS-...-AB-...
22
System status table
Operating mode
Actuator/ guar
d position
LED indicator
output
State
ST
ATE (gr
een)
ST
ATE (r
ed)
Normal operation
closed Normal operation, door closed and locked
closed 1 x Normal operation, door closed and not locked
open 1 x Normal operation, door open
Teach-in standby open 3 x
Door open; device is ready to learn a new actuator.
(only a short time after power up)
Setup
closed 1 Hz Teach-in operation
X Positive acknowledgment after completion of teach-in operation
Fault display X 1 x
Error in teach-in operation
(e.g. actuator removed from the operating distance prior to the end of the teach-in operation or disabled
actuator in the operating distance)
X 5 x Internal fault (e.g. component faulty, data error)
X X X Internal fault
Key to symbols
LED not illuminated
LED illuminated
10 Hz (8 s) LED flashes for 8 seconds at 10 Hz
3 x LED flashes three times
X Any state
After the cause has been remedied, faults can generally be reset by opening and
closing the door. If the fault is still displayed afterward, use the reset function or
briefly interrupt the power supply. Please contact the manufacturer if the fault could
not be reset after restarting.
Important:
If you do not find the displayed device status in the System status table, this indi-
cates an internal device fault. In this case, you should contact the manufacturer.
