Operating Instructions Safety Switch CES-AP-C01-AH
26
Ordering information and accessories
Designation Version Order
No.
CES-AP-C01-AH-SB-111145 Plug connector M12 5-pin, pin 5 not used, unicode 111145
Connection cable, 5-pin,
with flying lead
M12 female connector, 5-pin, length 5 m, PVC 100183
M12 female connector, 5-pin, length 10 m, PVC 100184
M12 female connector, 5-pin, length 20 m, PVC 100185
Extension cable
with M12 plug connector, 5-pin
5 m, PVC 100180
10 m, PVC 100181
20 m, PVC 100182
Actuator CES-A-BBA 42 mm x 25 mm 071840
Actuator CES-A-BPA 40 mm x 40 mm 098775
Actuator CES-A-BRN 80 mm x 40 mm 100251
Inspection and service
Warning!
Loss of the safety function because of damage to the system.
In case of damage, the related component must be replaced completely.
Only accessories or spare parts that can be ordered from EUCHNER may be
replaced.
Regular inspection of the following is necessary to ensure trouble-free long-term
operation:
Ì Check the switching function (see section Functional check)
Ì Check the secure fastening of the devices and the connections
Ì Check for soiling
No servicing is required; repairs to the device are only allowed to be made by the
manufacturer.
Note:
The year of manufacture can be seen in the lower right corner of the rating plate.
The current version number in the format (V X.X.X) can also be found on the device.
The safety door must be re-adjusted when the device indicates that the actuator
is in the limit range.
