Operating Instructions Safety Switch CES-AP-C01-AH
18
Technical data
Note:
If a product data sheet is included with the product, the information on the data
sheet applies in case of discrepancies with the operating instructions.
Technical data for safety switch CES-AP-C01-AH
Parameter Value Unit
min. typ. max.
Housing material PBT V0 GF30
Dimensions According to EN 60947-5-2
Weight 0.4 kg
Ambient temperature
at U
B
= DC 24 V
- 20 - + 55 °C
Storage temperature - 25 - + 70
Degree of protection
acc. to EN IEC 60529
IP 67
Safety class III
Degree of contamination 3
Installation position Any
Connection M12 plug connector, 5-pin
Operating voltage U
B
(reverse polar-
ity protected, regulated, residual
ripple < 5%)
24 ± 15% (PELV) V DC
For the approval according to
the following applies
Operation only with UL Class 2 power supply, or equivalent
measures
Current consumption 50 mA
Switching load according to DC 24 V, class 2
External fuse (operating voltage) 0.25 - 8 A
Safety outputs OA/OB Semiconductor outputs, p-switching, short circuit-proof
- Output voltage U(OA)/U(OB) 1)
HIGH U(OA)
U
B
-1.5 - U
B V DC HIGH U(OB)
LOW U(OA)/U(OB) 0 1
Switching current per safety output 1 - 400 mA
Utilization category
according to EN IEC 60947-5-2
DC-13 24 V 400 mA
Caution: outputs must be protected with a free-wheeling diode in
case of inductive loads.
Off-state current
according to EN IEC 60947-5-2
(OA/OB) 2)
- - 0.25 mA
Rated insulation voltage U
i
- - 300 3) V
Rated impulse withstand voltage U
imp
- - 1.5 kV
Resilience to vibration In acc. with EN IEC 60947-5-2
Switching frequency - - 1 Hz
Repeat accuracy R
acc. to EN IEC 60947-5-2
≤ 10 %
EMC protection requirements In accordance with EN IEC 60947-5-3 and EN IEC 61326-3-1
Reliability values acc. to EN ISO 13849-1
Category
4
Performance Level PL e
PFH
d
2.1 x 10 -9 / h
Mission time 20 years
1) Values at a switching current of 50 mA without taking into account the cable length.
2) Maximum current at an output in switched-off state.
3) Tested by employers’ liability insurance association up to 75 V.
