Requirements for connection cables
Caution!
Risk of damage to equipment or malfunctions as a result of incorrect connec-
tion cables.
Ì Use connection components and connection cables from EUCHNER
Ì On the usage of other connection components, the requirements in the fol-
lowing table apply. EUCHNER provides no warranty for safe function in case
of failure to comply with these requirements.
Ì Please observe the maximum cable length of 200 m.
Observe the following requirements with respect to the connection cables:
Parameter Value Unit
Conductor cross-section 0.34 mm²
R max. 60 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIYY 5x0.34 mm²
Connector assignment, safety switch CES-AP-C01
Figure 1: Connector assignment, safety switch CES-AP
Pin
Plug connector
Designation Description Wire color
5-pin,
pin 5 not used
1 UB Power supply, DC 24 V brown
2 OA Safety output, channel 1 green
3 0V Ground, DC 0 V blue
4 OB Safety output, channel 2 yellow
5 n.c. Not used gray
View on the connection side of the safety switch
Plug connector
3
5
4
1 2
5-pin 8
2
7
6
1
3
4
5
UB
0V
n.c.
n.c.
OA
OB
DIA
RST
1
3
2
4
5
UB
0V
OA
OB
DIA
1
3
2
4
5
UB
0V
OA
OB
n.c.
5-pin, pin 5 not used
