FIGURE 11—HYDRAULIC DECKS AND OIL COOLER
ITEM NO. QTY. PART NO.
DESCRIPTION
1
1
306195
WELDMENT - HYDRAULIC RESERVOIR
2
2
305737
DECK MOTOR - R, REAR DECKS, CCW
3
1
305736
DECK MOTOR - L DECK CW
4
1
305037
BASE - HYDRAULIC FILTER
5
1
07691
DECK VALVE MANIFOLD ASSY
6
1
07692
LIFT VALVE,
7
1
07683
OIL COOLER, HAYDEN #038674
8
1
07709
LIFT CYL - WING DECK, AURELIUS #
9
1
07710
LIFT CYL - REAR DECK, AURELIUS #
10
1
07783
CAP & FILL TUBE, HYDRAULIC RESERVOIR ASSY
11
5
07285
STRAIGHT ADAPTER STEEL
12
4
07810
SWIVEL NUT RUN TEE
13
3
07297
FITTING 6-V50X-S
14
1
07753
HOSE #20
15
4
07421
STRAIGHT THREAD ELBOW
16
1
07754
HOSE #21
17
1
07755
HOSE #22
18
1
07756
HOSE #23
19
1
07807
STRAIGHT THREAD RUN TEE
20
1
07813
TUBE END REDUCER
21
1
07757
HOSE #24
22
1
07758
HOSE #25
23
1
07759
HOSE #26
24
4
07811
STRAIGHT THREAD ELBOW
25
1
07760
HOSE #27
26
3
07800
STRAIGHT THREAD CONNECTOR
27
1
07761
HOSE #28
28
6
07287
STRAIGHT THREAD ELBOW
29
1
07762
HOSE #29
30
1
07763
HOSE #30
31
1
07764
HOSE #31
32
3
07281
STRAIGHT THREAD CONNECTOR
33
1
07765
HOSE #32
34
1
07766
HOSE #33
35
1
07767
HOSE #34
36
1
07768
HOSE #35
37
1
07769
HOSE #36
38
1
07279
REGULATOR
39
1
07825
FITTING 6F6X-S
40
1
07834
FITTING 6FTX-S STR
