I-TRIM ®
39
FIGURE 2—DECK LIFT ARMS AND PULL ARMS
IT
E
M
N
O
.
Q
TY.
P
ART
NO.
D
ESCRIPTION
1
2
07719
BUSHING - 1X1.5X2, BOSTON #B1624-16
2
5
02511
THRUST WASHER
3
1
02263
HEX NUT 3/8-24 NYLOCK
4
3
02403
FLAT WASHER - 3/8 SAE
5
1
07709
LIFT CYL - WING DECK
6
10
204447
BUSHING - PULL ARM
7
1
02036
HEX BOLT, 0.375 -24 UNF x 2¼ ZINC PL
8
1
306062
WELDMENT - LOWER PULL ARM, L
9
2
306188
WELDMENT - WING LIFT ARM
10
1
306191
WELDMENT - WING LIFT X-SHAFT
11
1
306061
WELDMENT - UPPER PULL ARM L
12
1
306242
NON SKID - WING PULL ARM
13
5
306177
BUSHING - PULL ARM INNER
14
1
04079
EXTERNAL RETAINING RING
, 1.00 ID, H/D, McM #98585A121
15
1
306359
NON SKID - WING PULL ARM
16
1
306232
WELDMENT - UPPER PULL ARM R
17
1
306234
WELDMENT - LOWER PULL ARM R
18
4
04048
ROLL PIN, .25 X 1.5
19
2
07714
LIFT SPRING - REAR PULL ARM
20
2
306320
END CAP - SPRING MOUNT, OUTER
21
1
07710
LIFT CYL - REAR DECK
22
1
306128
WELDMENT - LIFT ARM, RR PULL FRAME
23
2
02061
HEX BOLT, ½ -13 UNC x 1¼
24
1
306129
BUSHING - LONG, RR PULL FRAME
25
2
02333
EXTERNAL TOOTH LOCK WASHER, 1/2 ADAMS #348800
26
1
02751
HEX JAM NUT, NYLOCK, 3/4-16
27
1
306123
WELDMENT - PIVOT FRAME, RR PULL ARM
28
1
306241
PIVOT PIN - REAR DECK
29
1
306120
WELDMENT - LIFT FRAME, RR PULL ARM
30
2
306167
MOUNT - SPRING, RR DECK
31
2
306185
END CAP - SPRING MOUNT
32
2
02166
HEX BOLT, ½ -13 UNC x 5½
