HotBlock™: Operation and Instruction Manual Getting Started
11 • Environmental Express www.environmentalexpress.com / 800.745.8218 / 843.576.1147
Easily Name Your Programmed Methods.
Name your method AFTER programming all your steps and
parameters as described on page 10. To name a method, go to the
METHOD tab. Select the method number you wish to name, then click
on VIEW/EDIT. This will take you to the screen shown here (Figure
1). Click on the GRAY BAR (indicated in figure 1 by the red arrow) at
the top of the screen under the TABS. When you click on this bar, a
pop-up keypad will allow you to type in the method name. Then press
ENTER. When you choose the METHOD NUMBER you wish to run, the
METHOD NAME will appear in the BLUE BOX at the bottom of the
METHOD screen (see METHOD screen, Figure 2).
Easily Initiate a Stored Method.
To start a stored method go to the METHOD screen. Press the
METHOD button you wish to use, Then press RUN ON BLOCK 1 or
RUN ON BLOCK 2 accordingly.
Please note that the SOAK timer will not appear on the STATUS screen or
start counting down until the block temperature is within 3°C of
SET POINT temperature.
Method Screen, Figure 1. When you click on the gray bar, a pop-up keypad will enable you
to type in the method name.
Method Screen, Figure 2. To initiate a stored method go to the METHOD screen
and select the number of the method you wish to run. The method name will
appear in the blue box at the bottom of the screen.
