Ocarina/Castanet Installation Guide
Introduction
MAN-OCSIG (Ver. 1.4)
2-2
2.3
Fault Protection
Built-in protection against possible fault conditions, including:
•
Shorts between the outputs or between each output and the power input/return
•
Over-heating
•
Under/over voltage
•
Failure of internal power supplies
•
Latch mode for each protective feature
2.4
How to Use this Guide
Installation is the first step in integrating and operating the Elmo Ocarina and Castanet
servo amplifiers. After carefully reading the safety instructions in the first chapter, the
following chapters provide you with installation instructions as follows:
Chapter 3, Installation
, provides step-by-step instructions for unpacking, mounting
and connecting the Ocarina.
Chapter 4, Servo Control Operation
, explains how to control the operation of the servo
amplifier.
The
Appendix, Technical Specifications
, lists all the drive ratings and specifications.
