Ocarina/Castanet Installation Guide
MAN-OCSIG (Ver. 1.4)
2-1
Chapter 2: Introduction
This Installation Guide is intended for design engineers who are integrating an Elmo
Motion Control Ocarina and Castanet servo amplifiers into a machine.
2.1 Product Description
The Ocarina and Castanet series of servo-amplifiers was designed to deliver “the highest
possible power density”. The Ocarina can deliver up to 1.4 kW of continuous power or
2.8 kW of peak power in a matchbox size (2.25 in³ or 38cc) package. The Castanet delivers
up to 240 W of continuous power or 480 W of peak power.
The Ocarina and Castanet are designed for OEMs. They operate from a DC power source in
current mode in conjunction with a DC Brush and Brushless motors (refer to section 4.1).
The Ocarina and Castanet can operate as a stand-alone device.
There are two categories of Ocarinas and Castanets, 60 VDC versions and 100 VDC
versions. Power to the 60 V products is provided by a separate 0 ~ 59 V isolated DC
power source. Power to the 100 V products is provided by a separate 0 ~
9 5 V isolated
DC power source.
Note: There is a separate VL terminal for the control/logic supply input. In the 60 VDC
models this terminal can be connected to an external 11 ~ 59 VDC isolated supply. In the
100 VDC models this terminal can be connected to an external 12 ~ 95 VDC isolated
supply whenever the user wants to control the logic supply with an auxiliary low power
voltage source.
If power separation is not needed the VL and VP+ terminals can be shorted so that the
main
power supply will also power the control/logic supply and there will be no need
for a separate control/logic supply.
The Ocarina and Castanet are PCB mounted devices which enable efficient and cost
saving
implementation.
2.2 Highlights
• Operates in current mode
• 0 ~ 59 VDC isolated DC power source for 60 V models
• 0 ~ 9 5 VDC isolated DC power source for 100 V models
• Zero deadband
• Excellent linearity
• Differential current command input
• Motor current monitor
• Current gain change for low inductance motors
• Status indication by four open collector optos
• External continuous and peak current-limit adjustments
• Interface via 2 mm pitch 0.51 mm square pins
• Package: plated AL 6063T5 with electroless nickel, plastic housing,
UL94V0 recognized (Ocarina only)
• Ultra-compact size – Ocarina: 2.1" x 0.6" x 1.8" (55 x 15 x 46.5 mm),
Castanet: 2" x 0.49" x 1.65" (51 x 12.5 x 42 mm)
• Weight: Ocarina – 1.6 oz (45g), Castanet – 0.76 oz (21.5 g)
