Page 43

Gold Drum (D-Sub Connectors) Installation Guide
MAN-G-DRUM(DTYPE)IG-EC (Ver. 1.400)
||Digital Inputs and Outputs (P2)
43
9.11. Digital Inputs and Outputs (P2)
The Gold Drum Port C connector is a D-Type connector with 26 high density male pins. Refer to
Chapter 11 in the in the MAN-G-Panel Mounted Drives Hardware manual for full details.
The following table lists the digital input pin assignments.
I/O Pins(P2)
Signal
Function
1, 10
VDD
Supply for out 1-4
2
OUT1
Programmable output 1
3
OUT2
Programmable output 2
4
OUT3
Programmable output 3
5
OUT4
Programmable output 4
STO_OUT_E STO Emitter output option
(see Catalog/Part Number options)
6, 15
VDDRET
Supply return for out 1-4
7, 8
VL+
VL Supply Input Positive
9, 18
VL-
VL RET Supply Input Return
11, 12, 13, 16, 17,
26
None
Not Connected
14
STO_OUT_C STO Collector output option (see Catalog/Part Number options)
19
INRET1-6
Programmable inputs 1 to 6 return for the standard version
Programmable positive input 1 to 6 for the Sink version
20
IN1
High Speed, programmable input 1 (event capture, home,
general purpose, RLS, FLS, INH, PWM & direction input, pulse &
direction input)
21
IN2
High Speed, programmable input 2 (event capture, home,
general purpose, RLS, FLS, INH, PWM & direction input, pulse &
direction input)
22
IN3
High Speed, programmable input 3 (event capture, home,
general purpose, RLS, FLS, INH, PWM & direction input, pulse &
direction input)
23
IN4
High Speed, programmable input 4 (event capture, home,
general purpose, RLS, FLS, INH, PWM & direction input, pulse &
direction input)
24
IN5
High Speed, programmable input 5 (event capture, home,
general purpose, RLS, FLS, INH, PWM & direction input, pulse &
direction input)
25
IN6
High Speed, programmable input 6 (event capture, home,
general purpose, RLS, FLS, INH, PWM & direction input, pulse &
