WIRING INFORMATION
Rerun Architectural is designed to use daisy-chain wiring topology. Please give us a call if you have
any questions.
Note:
!
DMX512 from a console will not pass through if the Rerun Architectural is not powered .
CABLE COLOR FROM TO USE
1
120 O hm D ata C able
B elden 9829 or E quivalent
S hield
XLR P late
P in 1
R E R U N -A
D M X IN (C ) C om m on
W hite/B lue P in 2 D M X IN (-) D ata -
B lue/W hite P in 3 D M X IN (+) D ata +
2
(2) #16 A W G
S tranded W ires
B lack
P ow er S upply
C om m on P W R /D M X O U T (C ) S upply
R ed P ower P W R /D M X O U T (V ) S upply “hot”
5
120 O hm D ata C able
B elden 9829 or E quivalent
S hield
R E R U N -A
P W R /D M X O U T (C )
D im m er
C abinet
? C om m on
W hite/B lue P W R /D M X O U T (-) ? D ata -
B lue/W hite P W R /D M X O U T (+) ? D ata +
OPTIONAL REMOTE PANEL
CABLE COLOR FROM TO USE
1 120 O hm D ata C able
B elden 9829 or E quivalent
S hield
XLR P late
P in 1
P R E 10-A
S lave
T B 1-1 C om m on
W hite/B lue P in 2 T B 1-2 D ata -
B lue/W hite P in 3 T B 1-3 D ata +
2 (2) #16 A W G
S tranded W ires
B lack
P ow er S upply
C om m on T B 1-4 S upply
R ed P ow er T B 1-5 S upply “hot”
3 120 O hm D ata C able
B elden 9829 or E quivalent
S hield
P R E 10-A
S lave
T B 1-1
R E R U N -A
D M X IN (C ) C om m on
W hite/B lue T B 1-2 D M X IN (-) D ata -
B lue/W hite T B 1-3 D M X IN (+) D ata +
4 (2) #16 A W G
S tranded W ires
B lack T B 1-4 P W R /D M X O U T (C ) S upply
R ed T B 1-5 P W R /D M X O U T (V ) S upply “H ot”
5 120 O hm D ata C able
B elden 9829 or E quivalent
S hield
R E R U N -A
P W R /D M X O U T (C )
D im m er
C abinet
? C om m on
W hite/B lue P W R /D M X O U T (-) ? D ata -
B lue/W hite P W R /D M X O U T (+) ? D ata +
