SPECIFICATIONS
Connector: Terminal block #1
Phoenix Contact MSTB series
5 position two part terminal block
Model: MSTB 2,5/5-ST-5,08
Order number: 17 57 04 8 Terminal block #2
Phoenix Contact MSTB series
3 position two part terminal block
Model: MSTB 2,3-G-5,08
Order number: 17 55 74 9
Connector pin out: Terminal Block #1 (DMX512 Output) Terminal Block #2 (DMX512 Input)
1 (C) DMX512 common 1 (C) DMX512 common
2 ( -) DMX512 data - 2 ( -) DMX512 data -
3 (+) DMX512 data + 3 (+) DMX512 data +
4 (C) Supply common
(internally tied to pin1)
5 (V) Supply voltage “hot”
Input Circuit: ESD protected EIA-485 transceiver (LT1785)
Output Circuit: ESD protected EIA-485 transceiver (LT1785)
Isolation: None. DMX input is not isolated from DMX output.
Indicators:
Ten green SHOW LEDs
One green PAUSE LED
One green LOOP LED
One yellow START LED
One yellow END LED
One red INPUT/RECORD LED
User controls:
Ten [SHOW] buttons
One [PAUSE] button
One [LOOP] button
One [REWIND] button
One [FORWARD] button
One recessed [RECORD] button
Option Jumpers: INSTALLED REMOVED
JP1 Recording enabled Recording/editing disabled
JP2 Run show on DMX512 loss Hold last look on DMX512 loss
JP3 Normal operation Run hardware test
JP4 Normal operation Factory use only
JP5 Pile-on mode disabled Pile-on mode enabled
JP6 Normal operation Erase memory (DANGER!)
