Bowers & Wilkins ASW 2500 User Manual

Page 38

Description

Drive units

System frequency range

System frequency response

Amplifier

Internal Volume

Dimensions

Net Weight

ASW

™

2500

THX is a registered trademark of Lucasfilm Ltd.

B&W Loudspeakers Ltd. reserves the right to amend details of the specification without notice in line with technical developments.

Manufactured by B&W Loudspeakers Ltd, Meadow Road, Worthing, BN11 2RX

Tel: +44 (0) 1903 524801 Fax: +44 (0) 1903 524725 http://www.bwspeakers.com

Service/Distribution:

B&W (UK) Ltd, Marlborough Road, Lancing, West Sussex, BN15 8TR, England. Tel: 01903 750750 Fax: 01903 750694

B&W Loudspeakers of America, 54 Concord Street, North Reading, M.A. 01864-2699 United States of America

Tel: (978) 664-2870 Fax: (978) 664-4109

B&W Loudspeakers (Asia) Ltd, Flat U, 11F Camelpaint, Building Block 111, 60 Hoi Yuen Road, Kwun Tong, Kowloon, Hong Kong.

Tel: +(8522) 790 8903 Fax: +(8522) 341 2777

Active closed-box subwoofer

One 250mm (10 in) dia long throw

-6dB 20Hz - 50/150Hz adjustable (EQ at ‘B’)

±3dB 23Hz - 40/120Hz adjustable (EQ at ‘B’)

Power output

700W continuous (1kW short term)

Input impedance

15k

Ω

Sensitivity

88dB spl at 1m for 100mV input
(Volume control set to centre position)

Signal/Noise

90dB

Functions

Input level
Phase 0/180

Low-pass filter bypass
Low-pass filter frequency
Bass roll-off alignment
Auto-sense on/standby

Inputs

Line In (RCA Phono)

Outputs

Line Out (RCA Phono, h-p filtered)
Link Out (RCA Phono)

Low-Pass Filter

Active 2nd-order, variable cut-off 50Hz - 150Hz

High-Pass Filter

Active 2nd-order at 80Hz

15 litres (0.5 cu ft)

Height:

315mm (12.4 in) not including feet

Width:

315mm (12.4 in)

Depth:

402mm (15.8 in) including controls

23.4kg (51.5 lb)

II08494 Issue 1
