Det-Tronics C7052C UV/IR Flame Detector used with R7409 Controller - Manual (Page 2)

Figure 1—Dimensions of the C7052 Detector in Inches (Millimeters)
Figure 2—Optional Q9001G Swivel Mounting Bracket Dimensions in Inches (Millimeters)
5-1/4 INCHES
(133 MM)
2-1/2 INCHES
(64 MM)
MOUNTING BASE
1/2 INCH NUT USED TO ADJUST
ELBOW TO DESIRED ANGLE
1-3/8 INCH NUT USED TO ROTATE
SWIVEL/DETECTOR ASSEMBLY
TO DESIRED POSITION
3/4 INCH NUT USED TO
SECURE DETECTOR
BRACKET TO SWIVEL MOUNT
JUNCTION BOX MOUNTING
BRACKET (ATTACHES
WITH TWO ENCLOSED
FLATHEAD SCREWS)
2–1/2 (64 MM) DIA.
0.25 (6.4 MM)
DIA. (3)
120
° ±
2
°
(2)
2.00 (50.8 MM) DIA.
B1303
B1303
C1047
3.38 (85.8 MM) 7.11 (181 MM)
7.81
(198 MM)
2.5 DIA.
(64 MM)
5.25
(133 MM)
CONDUIT ENTRY 3/4 NPT OR 25 MM
