19
Pre-Startup Checklist

Know the system. Read this manual carefully. Make use of its instructions and
explanations. The know how of safe, continuous, satisfactory, trouble-free
operation depends primarily on the degree of your understanding of the system
and of your willingness to keep all parts in proper operating condition.

Check line voltage. This must correspond to nameplate requirements of motors
and controls. A wrong voltage can result in serious damage. Refer to the
section on power connections in the INTRODUCTION of this manual.

Check fresh air & exhaust dampers (Non-atmosphere models only). Do not be
careless about restrictions in and around the fresh air and exhaust openings and
stacks. Under no condition, permit them to become so filled with dirt that they
reduce airflow.
Startup
For fastest oven heat-up time, close the
vent (fresh air models). After desired
temperature is reached, vent may be
adjusted as needed.
1.
Start fan.
a. Open oven door.
b. Press POWER toggle switch to the ON
position. You will hear the recirculating
fan start.
c. Shut oven door.
d. Check that the amber LED on the CONTROL panel is on.
2.
Enter setpoint on the CONTROL instrument.
3.
Set HIGH LIMIT instrument to a temperature 10 C - 15 C higher than the
setpoint or to a temperature that should not be exceeded in the process. It will
be necessary to reset the HIGH LIMIT instrument whenever it has tripped. To
reset, allow the oven to cool slightly or increase the HIGH LIMIT setpoint above
the actual temperature. Press the RESET button.
WARNINGS: Do not use any flammable solvent or other
flammable material in this oven. Do not
process closed containers of any substance
or liquid in this oven because they may
explode under heat.
WARNING: DO NOT touch cooling coil drain
piping during chamber operation
- steam can be generated in the
cooling coil and STEAM BURNS.
