14
The brass needle valve on the face of the
water flowmeter can be used for adjusting the
water flow or shutting off the water flow.
i. Run tubing from flowmeter to water valve.
ii. Connect a clean water supply to the flowmeter marked inlet.
iii. Adjust the water flow. Cooldown times and steam generation are
dependent on cooling water flow rate. Recommended flow rate is
50 gallons per hour.
c. The pipe on the rear of the oven marked WATER DRAIN should be piped
to a vacuum breaker and then to an open drain.
WARNING: never allow
drain to be plugged as a
hot oven will generate a
small amount of steam
when the water is first
turned on. Steam
burns.
WARNING: All grounding and safety
equipment must be in
compliance with
applicable codes,
ordinances and accepted
safe practices.
