7
MIC 1462 PROFILE PROGRAMMING
Programming a profile into the MIC1462 control is broken into three categories:
GLOBAL - Those parameters common to all programs.
PROGRAM - Those which apply to a specific program as a whole.
SEGMENT - Those relevant to a specific segment in a specific program.
Global Parameters (common to all programs)
(Program Number = A, Segment Number = Blank)
1. Press the mode key until the message display reads “Prof Par”.
2. Press the scroll key once.
3. Press the Prof key until the program number display reads “A”.
4. The global parameters will now be displayed in the message display and the
setting will be displayed in the lower display.
5. Press the scroll key to go from one parameter to the next.
6. Press the up or down arrow to change the displayed setting.
The parameters common to all programs (global parameters) are presented for
editing/viewing in the following sequence:
Global Profile Parameters Table
STEP DESCRIPTION MESSAGE
DISPLAY
FUNCTION AVAILABLE SETTING
1 Start On Start On Defines setpoint value
at start of each
program SEtP - Current Controller setpoint
value
Proc - Current Process variable
value
2 Go To Go To Defines Base Mode
Status and end of each
program On - Outputs are active
Off - Outputs are inactive
3 End On End on Defines setpoint value
at end of each program
F_SP-End on Final SP value *
SEtP-End on Controller SP value
4 Delay Time Delay Defines delay (in
hours/min) between
initiating the program
and actually starting Numerical value, with the decimal
point separating the hours and
minutes.
