9
Program Parameters (apply as a whole to a specific program)
(Program Number = 1 to 8, Segment = Blank)
1. Press the mode key until the message display reads “Prof Par”
2. Press the scroll key once.
3. Press the Prof key until the desired program # is shown in the program number
display.
4. The program parameters will now be displayed in the message display and the
setting will be displayed in the lower display.
5. Press the scroll key to go from one program parameter to the next.
6. Use the up and down arrows to change the setting.
Only the parameters relevant to the displayed program number (which can be changed
using the PROG key) are presented. The parameter sequence is as follows:
Program Profile Parameters Table
STEP DESCRIPTION MESSAGE
DISPLAY
FUNCTION AVAILABLE SETTING
1 Cycle Count Cycles Defines the number of
times the program will be
repeated 1-9999
Program will repeat the set
number of times
inF = Program will repeat
indefinitely
2 Deviation Hold Dev.Hold Selects operation of
Deviation Hold facility
(relative to setpoint) OFF = No Deviation Hold
H_SP = Deviation Hold above
setpoint only
L_SP = Deviation Hold below
setpoint only
both = Deviation Hold above and
below setpoint
3 * Hold Band HoldBand Defines the width of the
Hold Band Numerical value (0.0 to span)
4 * Hold On Hold on Defines whether the
Deviation Hold facility is
used on ramps only,
dwells only or both d_r = Deviation Hold on ramps
and dwells
d = Deviation Hold on dwells only
r = Deviation Hold on ramps only
5 Pre-x60 Pre-x60 Determines whether the
timebase for the program
is pre-selected to be
hours/minutes or
minutes/seconds nonE = No pre-selection
On = Operates MINS/SECS
OFF = Operates HRS/MINS
6 Autostart time
Enable Timer Selects whether autostart
is active for this profile On
OFF
